D&H Secheron Supratherme Welding Electrode 4mm 450mm Get Best Offer Price

Original price was: ₹3,200.00.Current price is: ₹3,150.00.

D&H Secheron Supratherme Welding Electrode 4mm 450mm Get Best Offer Price
Characteristics and Applications A heavy coated low hydrogen, iron powder type electrode ideally suited for producing tough and ductile welds of radiographicquality in boilers, pressure vessels and heavy structures subjected to dynamic loading. The lectrodes have a metal recovery of about 115%. Some typical applications include heavy structures subjected to dynamic loading and impact, highly restrained joints, coaches, wagons, penstocks, boilers, pressure vessels, earthmoving machines, etc. Typical Chemical compotion of all weld metal: C – 0.06%, Mn-1.06%, Si-0.44%, S-0.022%, P-0.022% Typical Mechanical properties of all weld metal – UTS (MPa) 545, YS (MPa) 460, Elongation (L=4d)% 28, CVN Impact strength at minus 30degree C (Joules) – 65
Current Range: 150-190 Amps Approvals: ABS, Adani Infra, BHEL, BIS, BV, CIB-MO, DNV, EIL, Indian Navy, IRS, L&T Power, LRA, NPCIL, NTPC, PDIL, Reliance (Engineering) Precaution: Enusre th electrodes are dry. Redry the moist electrodes as per our standard recommended pratice

Category: Welding Rods

D&H Secheron Supratherme Welding Electrode 4mm 450mm Get Best Offer Price
Characteristics and Applications A heavy coated low hydrogen, iron powder type electrode ideally suited for producing tough and ductile welds of radiographicquality in boilers, pressure vessels and heavy structures subjected to dynamic loading. The lectrodes have a metal recovery of about 115%. Some typical applications include heavy structures subjected to dynamic loading and impact, highly restrained joints, coaches, wagons, penstocks, boilers, pressure vessels, earthmoving machines, etc. Typical Chemical compotion of all weld metal: C – 0.06%, Mn-1.06%, Si-0.44%, S-0.022%, P-0.022% Typical Mechanical properties of all weld metal – UTS (MPa) 545, YS (MPa) 460, Elongation (L=4d)% 28, CVN Impact strength at minus 30degree C (Joules) – 65
Current Range: 150-190 Amps Approvals: ABS, Adani Infra, BHEL, BIS, BV, CIB-MO, DNV, EIL, Indian Navy, IRS, L&T Power, LRA, NPCIL, NTPC, PDIL, Reliance (Engineering) Precaution: Enusre th electrodes are dry. Redry the moist electrodes as per our standard recommended pratice
